Power inspection long endurance quadrotor drone H401
Adavntage H401 Hexacopter drone chassis is carbon fiber unibody molding, the overall quality of light, high strength, high toughness, high temperature resistance, good rainproof, high flight stability! Performance Parameters Fuselage Material...
Power inspection long endurance quadrotor drone H401
Adavntage
H401 Hexacopter drone chassis is carbon fiber unibody molding, the overall quality of light, high strength, high toughness, high temperature resistance, good rainproof, high flight stability!
Performance Parameters
|
Fuselage Material |
Toray 3K Carbon Fiber |
|
Manufacturing Process |
High temperature and high pressure molding |
|
Thickness |
Regular 0.6mm |
|
Weight of casing |
1.5KG |
|
Weight of housing + power unit |
4.5KG |
|
Wheelbase |
1000mm |
|
Expansion Dimension |
1120mm*810mm*470mm |
|
Wheelbase |
1200mm |
|
Unfolded Dimensions |
1320mm*1200mm*470mm |
|
Folded Dimensions |
460mm*420mm*470mm |
|
Battery compartment |
205mm*135mm*90mm |
|
Recommended load |
3-5KG |
|
Unloaded Endurance |
＞70min |
|
Load capacity 3KG |
＞60min |
|
Whole machine without mounting weight (Red Dot 6s 27000*2 pieces)
|
9KG |
|
Control Distance
|
30KM (handheld ground station control), optional 4G/5G satellite communication unlimited distance |
Suitable for mounting
About Purchase
You are free to choose buy the following drone components according to your needs:
Optional 1: Drone Frame Type: H401-F
Optional 2: Drone Frame with Propulsion System Type: H401-P (Including airframe,motor, ESC, propeller blade)
Optional 3: Drone with Ready To Fly . Type: VF20E-R
