FF01 portable fixed-wing hand throw drone FPV drone
FF01 portable fixed-wing hand throw drone FPV drone
Product Overview
SKYWING FF01 is the hand-thrown lightweight aerial drone that can also rival FPV,Why we creat it?
Fixed-wing aircraft, in contrast to quadcopters, offer superior efciency, extended fight times, and greater range, but their large size and demanding takeoff/landing space requirements compromise portability. Traditional fixed-wing designs feature non-modular bodies, making them cumbersome to transport and prone to accidents, coupled with subpar video transmission quality that detracts from the overall flying experience. The creation of HAOHAN aims to tackle these issues head-on, restoring elegance to fight.
The application of high-lift airfoil problemles, wing twist, and elliptical lift distribution in drone’s wing design ensures both effcient fight and a superior stall resistance.
Performance Parameters
|
Overall Dimensions |
1080×690×376mm |
|
Installation Time |
<1min |
|
Standard takeoff Weight |
1100g |
|
Maximum endurance time |
70min(4S1P 21700)160min(4S2P21700) |
|
Maximumrange |
60km(4S1P21700)150km(4S2P 21700) |
|
Maximum operating altitude |
4000m |
|
Max takeoff weight |
<2Kg |
|
Flight Speed |
10m/s-27.7m/s |
|
Cruising Speed |
15.8m/s |
|
Wind Resistance Level |
Level5 |
|
Remote Control Range |
10km(In open or spacious condition) |
|
Packaging Box Dimensions |
583×453×256mm |
Optional Configuration version for FF01
