SKYWING Long Range Cargo Drone Fixed Wing UAV SE5000 KIT

SKYWING Long Range Cargo Drone Fixed Wing UAV SE5000 KIT
SKYWING SE5000 Carbon Fiber UAV Platform is a state-of-the-art unmanned aerial vehicle designed for professional use. Engineered with high-grade carbon fiber, this UAV offers unparalleled durability while being lightweight. It boasts a wingspan of 5000mm and a maximum take-off weight of 100~150kg, allowing for a generous payload capacity of 20~30kg. With a cruise speed of 120km/h and a maximum speed of 150km/h, The drone is built for both speed and endurance. It can fly up to 3 hours on just 6 liters of fuel, making it an economical choice for extended missions.
The platform also offers customizable power packages (additionally charge), either gasoline or electric, to suit specific operational needs. Overall, the SE50 is a versatile, reliable, and high-performance UAV ideal for a wide range of professional applications.
SKYWING UAV SE5000 Fixed Wing | |||
Name | Specification | KIT | PNP |
Flying platform | Outer wing | 2 | 2 |
Center wing | 1 | 1 | |
Main body | 1 | 1 | |
undercarriage | 1 | 1 | |
Plain tail | 1 | 1 | |
Stern stay | 2 | 2 | |
Front stay | 2 | 2 | |
hatchcover | 1 | 1 | |
Fuel tank | 1 | 1 | |
Engine hood | 1 | 1 | |
Power system | DLE170 Engine | 1 | |
Servo | 9 | ||
32*12 Propeller | 1 | ||
Wire bale | 1 | ||
Installation service | 1 |
PARAMETER | wingspan | 5000mm |
Length | 3670mm | |
Maximum fuselage width | 375mm | |
Wing area | 261.5 dm2 | |
Equipment bay dimensions | 920mmx340mmx350mm | |
Tank volume | 30L | |
Weight and Payload | Empty weight | 33.64kg |
Maximum take-off weight | 90KG | |
payload | 25KG | |
Flight Characteristics | Top speed | 150km/h |
Cruising speed | 120km/h | |
Stall speed | 55km/h | |
Take-off distance | 60M | |
Landing distance | 85M | |
Maximum flight time | >10H | |
Packaging Information | Wing section | 190*50*80cm |
Fuselage section | 190*50*48cm |
